◆技術規格 Main technical parameters (請繼續瀏覽訪問有個量應用案例圖片供參看)
器機產品型號 Model |
STR-9070/9080 |
STR-1010 |
工作上艙大小 Internal size(mm) |
900×800×650 |
1000×1000×790 |
該機的尺寸 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
開關電源 Power |
220V 50Hz |
220V 50Hz |
絲機照明工作燈 Machine floodlight |
一個60W隔爆燈 |
220V 13W工業節能燈管 |
滾簡承擔 Roller bearing |
10-30Kg |
10-30Kg |
轉移器減速機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
脫離器功率 Separator air volume |
8.5m3/min |
8.5m3/min |
再壓縮的空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
電腦單重 Weight |
320kg |
380 kg |
◆車輛結構特征 Product features
1. 設計制作新創意、顏值畢節、組成部分科學性、運營利于;
2. 智能把握智能噴砂,應具定時開關噴砂,點動位置定位等職能;
3. 輥子外徑及噴槍數可表明客服具體需求的設計加工制作;
4. 便可手動擋,又可一鍵,噴砂質量好,一機最好用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆適用于依據 Applicable scope
符合于過多小零件的帶有大量手動或自主噴砂,舉個例子:電竹木品、螺栓、塑料板材制
品、鈕扣、隱形拉鏈、有機玻璃、儀器零機械部件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
