H形鋼/剛板拋丸清潔機

◆新產品設備構造 Product structure

該設備常見是由處理室、屋內傳輸輥道與入進傳輸輥道、拋丸器、彈丸配置體統 ( 含提高自己機、分離處理器、縱覽螺旋葉片運輸器和供丸管 ) 、吹掃醫院、濾塵、電氣設備把握等性能部位組建。

This machine is mainly composed of clean room, indoor rollor conveyeer and in and out of rollor conveyeer, shot device, projectile circulation system (including hoist, separator, vertical and horizontal conveyor for spiral pipe) , purging institutions, dust removal, electrical control function components.

◆車輛道理 Product principle

為不間斷送料機的高功用不間斷上班清洗機，在清洗期間中由電力電氣把握的可調頻變速的推送輥道將鋼形式件或不銹鋼板規格材、鋼板規格送進清洗機室肚子里拋射區時，其全身各面由于源于八臺差異座標方向位置的拋丸器的強效分散彈丸的打怪與摩擦，使其上的防氧化銹層及污漬在短時間滑落，不銹鋼板規格材外壁就擁有兼有必須粗糟度的油亮外壁。闖進不銹鋼板規格材方面的彈丸與銹塵經的回收利用槽式推送至彈丸嵌套無限循環設備，在清洗室處中間輥道工作效率高零件。清洗期間中，撒落了來的丸塵搭配物經室體漏斗、縱橫交錯向槽式推送機匯總于增強自己機下處，再增強自己到機上方的離心離心過濾器里，離心脫離后的清爽彈丸闖進離心離心過濾器料桶中，供拋丸嵌套無限循環在使用。拋丸清洗中所產生污物，由抽搐管送向排塵設備，油煙活性炭過濾整理后的凈氣擺放到美觀磅礴中；顆粒狀污物，由抽搐管送向排塵設備，油煙活性炭過濾整理后的凈氣擺放到美觀磅礴中，顆粒狀污物入獄捉回收。

Continuous high function of feeding a continuous work cleaning machine, in the process of cleaning up from the electrical control can be variable frequency speed rollor conveyeer steel structure or steel, and will send into steel cleaning up machine room area, its trajectory in the whole face from each by eight  different coordinates the location of the powerful dense is shot of the projectile attack and friction, make its oxidation rusty layer and dirt quickly fall off, steel surface roughness has certain the bright and clean for surface. Fall into steel above with rust dust the projectile recycling helical conveyer to projectile circulation system, the clear channel outdoor both sides in unloading workpieces. In the process of cleaning up,  breaking down the Chambers blasting dust mixture, and vertical and horizontal funnel to screw conveyor are collected to hoist the lower, and then promoted to the upper part of the machine, after the separation in the separator pure projectile into separator, is shot in the hopper for recycling. Is shot from the dust, cleaning up by convulsions tube send to dust removal system, the purification processing of the net after gas emissions into the atmosphere; Granular dust by convulsions tube, send to dust removal system, the purification process after the net gas emissions into the atmosphere, the granular dust was caught and collected.

H形鋼/角鋼拋丸徹底清除機

◆ 產品的優缺點 Product features

不銹鋼板噴砂機都是種進行清潔 H 鋼、槽鋼、網架、不銹鋼的多工作鋼坯拋丸預凈化處理的設備。拋丸器布置準備模式為多方向角，選則了增進效率拋丸器，拋射精飛速密集區的彈丸束，查處在原使壯態鋁件表明的所有部件實現立體化的、全位子的整理，使鋁件表明各表明上的生銹層、焊渣、脫色皮十分它污染物快速發展掉了，有都具有特定越來越粗糙度的光亮表明，增進了油漆與鋼坯表明的支承力，并增進鋁件表明的抗疲憊值和抗腐蝕不銹鋼力量，提高了鋁件表明底層服務質量，延緩其適用人類壽命。

Steel shot machine is a clear H steel, steel, rack, steel, the multi-function steel is shot pretreatment equipment. Peen-forming decorate a form for the multiple perspectives, choose the advanced efficient peen-forming is a dense, aerosol propellant high speed of the projectile, blow the original state in parts of stereo, full range of cleaning, to make the work on the surface of the corrosion layer, welding slag and oxide skin and other contaminants quickly fall off, get has certain roughness of surface is bright and clean, improve the paint film with steel surface adhesion, and improve the resistance of fatigue and corrosion resistance, and improve the quality of the inner and prolong the service life.

◆ 具體的技術基本參數 Main technical parameters
