◆成品基本特征 Product features
1. 設定有意思,外觀簡約時尚美觀度,綠色環保實際好;
2. 隨意調節式風暴溶合器,能將都可以耐磨材料磨具與很小粉塵濃度溶合,好的耐磨材料磨具繼讀用;
3. 最主要的零安全裝置通過質量上乘進口工件,實用年限長;
4. 加工處理部件表層勻;
5. 多工裝夾具裝修設計;進行管理員可并且進行進行噴砂。可根據潛在客戶市場需求,供選擇擇帶有大量手動或自然 ;可按投資者請求制作廠!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆采用空間 Applicable scope
裝修板材,網吧電腦設備殼,影響控制面板,漢堡包烤盤等品面及方體鏜孔的噴砂加工處理。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆一般高技術叁數 Main technical parameters
儀器款式 Model |
STR-多工位輸送式噴砂機 |
主機面積 Complete machine size(mm) |
3000×1000×1700 |
本職工作服務器 Work space(mm) |
2000×1000×800 |
外氣流輸送厚度 Conveying the size(mm) |
500×1000×1000(2件) |
除灰箱外形尺寸 Dedust box sizes(mm) |
600×600×1800 |
轉移器三相電機 Separator motor |
220V 50HZ 550W |
提取器新風量 Separator air volume |
8.5m3/min |
壓解水汽源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W防燃燈 |
器機體積 Machine weight |
550kg |
